Stored Parameter List (SPL)
Below is a table of stored parameters followed by descriptions of each parameter.
Index Description Values Setting Meaning
1 Auto Level 0 - 1 1 disabled - enabled
2 Auto Second Level 0 - 1 1 disabled - enabled
3 Auto Lock 0 - 1 1 disabled - enabled
4 Baud Rate 0 - 4 2 0 = 9600, 1 = 19200,
2 = 38400, 3 = 57600,
4 = 115200
5 RW 485 Transmit Delay (ms) 2 - 200 10 2 - 200 ms
Parameter Descriptions
1. Auto Level configuration affects the result of turning the encoder. Turning the
encoder without pushing it in updates the command state to an Encoder Left for a
counter clockwise turn or an Encoder Right for a clockwise turn unless the device
is locked. If Auto Level is enabled (a value of 1), the main level is updated and in-
dicated by the LED as well. The Auto Level configuration also affects the Encoder
Input Commands IS and ISR. See Encoder Input Commands section for details
of how these commands are affected.
2. Auto Second Level configuration affects the result of turning the encoder while it
is pushed in. Turning the encoder while pushing it in updates the command state
to a Second Level Left for a counter clockwise turn or a Second Level Right for a
clockwise turn unless the device is locked. If Auto Second Level is enabled (a value
of 1), the second level is updated and indicated by a flashing LED as well. The
flashing LED is only visible when the encoder is pushed in. The Auto Second Level
configuration also affects the Encoder Input Commands IS, ISR, and IF. See En-
coder Input Commands section for details of how these commands are affected.
3. Auto Lock configuration affects the operation of the device when the lock input is
shorted to -V. If the device is configured for Auto Lock (a value of 1) and the Lock
input is shorted to -V, the encoder is locked out regardless of the software lock
status (see ILK command on page Manual-13). If the device is not configured for
Auto Lock (a value of 0), the Lock input is ignored and the encoder’s lock state is
defined by the software lock status.
4. This parameter sets the baud rate of the device. When this parameter is changed
via a RW 485 message, the response is sent at the current baud rate, then the baud
rate is updated to the new baud rate specified by the value sent. The default setting
of 38400 is required for use with Rane controllers (i.e., RPM 88/44/22). It can be
restored by holding the encoder in during power-up for several seconds until the
encoder LED turns on.
5. This parameter sets the minimum time in milliseconds the remote waits after
receiving a RW 485 message before it transmits a response. It is recommended
that this value not be changed. The default setting can be restored by holding the
encoder in during power-up for several seconds until the encoder LED turns on.
