PNOZ s7.2
Operating Manual PNOZ s7.2
21866-EN-08
10
Relay outputs 750177 751177
Safety contacts, DC13 (6 cycles/
min) at
24 V 24 V
Max. current 5,0 A 5,0 A
Contact fuse protection, external
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Circuit breaker, 24V AC/DC,
characteristic B/C
6 A 6 A
Contact fuse protection, external
auxiliary contacts
Blow-out fuse, quick 4 A 4 A
Blow-out fuse, slow 2 A 2 A
Circuit breaker, 24 V AC/DC,
characteristic B/C
2 A 2 A
Contact material AgCuNi + 0,2 µm Au AgCuNi + 0,2 µm Au
Conventional thermal current
while loading several contacts
750177 751177
Ith per contact at UB DC
Conv. therm. current with 1 con-
tact
6,00 A 6,00 A
Conv. therm. current with 2 con-
tacts
5,50 A 5,50 A
Conv. therm. current with 3 con-
tacts
4,50 A 4,50 A
Conv. therm. current with 4 con-
tacts
4,00 A 4,00 A
Times 750177 751177
Switch-on delay
With automatic reset after power
on typ.
30 ms 30 ms
With automatic reset after power
on max.
50 ms 50 ms
Delay-on de-energisation
With E-STOP typ. 18 ms 18 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 18 ms 18 ms
With power failure max. 30 ms 30 ms
Environmental data 750177 751177
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
EMC EN 60947-5-1, EN 61000-6-2, EN
61000-6-4
EN 60947-5-1, EN 61000-6-2, EN
61000-6-4
