PSEN op bracket turnable (kit)
Operating instructions
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany 1
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected] Original document
Scope of supply
Package contents:
 rotating brackets (4 pieces)
 M2x6 Allen screws (12 pieces)
Assembly
Place the rotating bracket near to the corresponding light curtain
cap protrusion (Fig.1, Fig.2).
Fig. 1 Fig. 2
Orient the bracket according to the desired rotation angle. Use an
Allen key to tightly fix the screws (2).
1
2
