Schutzart

Protection type

Indice de protection

IP67 No. 541209, 541210
IP6K9K No. 541211

Material

Material

Matériau

Gehäuse

Housing

Boîtier

PBT

Abmessungen siehe Abbildung

Dimensions, see graphic

Dimensions, voir l'illustration

Gewicht

Weight

Poids

Sensor

Sensor

Capteur

230 g No. 541211
35 g No. 541209, 541210

Betätiger

Actuator

Actionneur

15 g

Sicherheitstechnische Kennda-
ten

Safety-related characteristic
data

Caractéristiques techniques de
sécurité

PL nach EN ISO 13849-1: 2006

PL in accordance with EN ISO
13849-1: 2006

PL selon EN ISO 13849-1: 2006

PL e (Cat. 4)

Kategorie nach EN 954-1

Category in accordance with EN
954-1

Catégorie selon EN 954-1

Cat. 4

SIL CL nach EN IEC 62061

SIL CL in accordance with EN IEC
62061

SIL CL selon EN IEC 62061

SIL CL 3

PFH nach EN IEC 62061

PFH in accordance with EN IEC
62061

PFH selon EN IEC 62061

2,62E-09

SIL nach IEC 61511

SIL in accordance with IEC 61511

SIL selon IEC 61511

SIL 3

PFD nach IEC 61511

PFD in accordance with IEC 61511 PFD selon IEC 61511

7,68E-05

T

M

[Jahr] nach EN ISO 13849-1:

2006

T

M

[year] in accordance with EN

ISO 13849-1: 2006

T

M

[année] selon EN ISO 13849-1:

2006

20

Es gelten die 2009-01 aktuellen Ausgaben der
Normen.

The standards current on 2009-01 apply.

Les versions actuelles 2009-01 des normes
s'appliquent.

Bestelldaten

Order reference

Références

Typ/Type/Type

Stück/
Quantity/
Nombre

Wirkweise/Operation/Ac-
tionnement

Merkmale/Features/ Caractéri-
stiques

Bestell-Nr./Order
no./Référence

PSEN cs4.2a/PSEN cs4.1

1/1

Transpondertechnik/Trans-
ponder technology/Technique
à transpondeur

Sicheres Schutztürsystem, unikat
codiert/Safety gate system, uniquely
coded/Système de sécurité pour
protecteurs mobiles, codé unique

541 211

PSEN cs4.2p/PSEN cs4.1

1/1

Transpondertechnik/Trans-
ponder technology/Technique
à transpondeur

Sicheres Schutztürsystem, unikat
codiert/Safety gate system, uniquely
coded/Système de sécurité pour
protecteurs mobiles, codé unique

541 210

PSEN cs4.2 M12/8-0.15m/PSEN
cs4.1

1/1 Transpondertechnik/Trans-

ponder technology/Technique
à transpondeur

Sicheres Schutztürsystem, unikat
codiert/Safety gate system, uniquely
coded/Système de sécurité pour
protecteurs mobiles, codé unique

541 209

EG-Konformitätserklärung

1139424011

Diese(s) Produkt(e) erfüllen die Anforderungen
der Richtlinie 2006/42/EG über Maschinen des
europäischen Parlaments und des Rates. Die
vollständige EG-Konformitätserklärung finden
Sie im Internet unter www.pilz.com.
Bevollmächtigter: Norbert Fröhlich, Pilz GmbH
& Co. KG, Felix-Wankel-Str. 2, 73760 Ostfil-
dern, Deutschland

EC Declaration of Conformity

This (these) product(s) comply with the require-
ments of Directive 2006/42/EC of the European
Parliament and of the Council on machinery.
The complete EC Declaration of Conformity is
available on the Internet at www.pilz.com.
Authorised representative: Norbert Fröhlich,
Pilz GmbH & Co. KG, Felix-Wankel-Str. 2,
73760 Ostfildern, Germany

Déclaration de conformité CE

Ce(s) produit(s) satisfait (satisfont) aux exigen-
ces de la directive 2006/42/CE relative aux ma-
chines du Parlement Européen et du Conseil.
Vous trouverez la déclaration de conformité CE
complète sur notre site internet www.pilz.com.
Représentant : Norbert Fröhlich, Pilz GmbH &
Co. KG, Felix-Wankel-Str. 2, 73760 Ostfildern,
Allemagne

Mechanische Daten

Mechanical data

Données mécaniques
