Cypress Perform CY7C1513KV18 - Manual (Page 22)

CY7C1511KV18, CY7C1526KV18
CY7C1513KV18, CY7C1515KV18
Document Number: 001-00435 Rev. *E Page 22 of 31
I
DD
[21] V
DD
Operating Supply V
DD
= Max,
I
OUT
= 0 mA,
f = f
MAX
= 1/t
CYC
200 MHz (x8) 430 mA
(x9) 430
(x18) 440
(x36) 580
167 MHz (x8) 380 mA
(x9) 380
(x18) 390
(x36) 510
I
SB1
Automatic Power Down
Current
Max V
DD
,
Both Ports Deselected,
V
IN
≥ V
IH
or V
IN
≤ V
IL
f = f
MAX
= 1/t
CYC
,
Inputs Static
333 MHz (x8) 290 mA
(x9) 290
(x18) 290
(x36) 290
300 MHz (x8) 280 mA
(x9) 280
(x18) 280
(x36) 280
250 MHz (x8) 270 mA
(x9) 270
(x18) 270
(x36) 270
200 MHz (x8) 250 mA
(x9) 250
(x18) 250
(x36) 250
167 MHz (x8) 250 mA
(x9) 250
(x18) 250
(x36) 250
AC Electrical Characteristics
Over the Operating Range [13]
Parameter Description Test Conditions Min Typ Max Unit
V
IH
Input HIGH Voltage V
REF
+ 0.2 – – V
V
IL
Input LOW Voltage – – V
REF
– 0.2 V
Electrical Characteristics
(continued)
DC Electrical Characteristics
Over the Operating Range [14]
Parameter Description Test Conditions Min Typ Max Unit
