CY7C1511KV18, CY7C1526KV18
CY7C1513KV18, CY7C1515KV18
Document Number: 001-00435 Rev. *E Page 18 of 31
Identification Register Definitions
Instruction Field
Value
Description
CY7C1511KV18 CY7C1526KV18 CY7C1513KV18 CY7C1515KV18
Revision Number
(31:29)
000 000 000 000 Version number.
Cypress Device ID
(28:12)
11010011011000100 11010011011001100 11010011011010100 11010011011100100 Defines the type of
SRAM.
Cypress JEDEC ID
(11:1)
00000110100 00000110100 00000110100 00000110100 Allows unique
identification of
SRAM vendor.
ID Register
Presence (0)
1 1 1 1 Indicates the
presence of an ID
register.
Scan Register Sizes
Register Name Bit Size
Instruction 3
Bypass 1
ID 32
Boundary Scan 109
Instruction Codes
Instruction Code Description
EXTEST 000 Captures the input and output ring contents.
IDCODE 001 Loads the ID register with the vendor ID code and places the register between TDI and TDO.
This operation does not affect SRAM operation.
SAMPLE Z 010 Captures the input and output contents. Places the boundary scan register between TDI and
TDO. Forces all SRAM output drivers to a High-Z state.
RESERVED 011 Do Not Use: This instruction is reserved for future use.
SAMPLE/PRELOAD 100 Captures the input and output ring contents. Places the boundary scan register between TDI
and TDO. Does not affect the SRAM operation.
RESERVED 101 Do Not Use: This instruction is reserved for future use.
RESERVED 110 Do Not Use: This instruction is reserved for future use.
BYPASS 111 Places the bypass register between TDI and TDO. This operation does not affect SRAM
operation.
