Write Cycle Descriptions

The write cycle description table for CY7C1511KV18 and CY7C1513KV18 follows.

[2, 10]

BWS

0

/

NWS

0

BWS

1

/

NWS

1

K

K

Comments

L

L

L–H

During the data portion of a write sequence

:

CY7C1511KV18

− both nibbles (D

[7:0]

) are written into the device.

CY7C1513KV18

− both bytes (D

[17:0]

) are written into the device.

L

L

L-H During the data portion of a write sequence

:

CY7C1511KV18

− both nibbles (D

[7:0]

) are written into the device.

CY7C1513KV18

− both bytes (D

[17:0]

) are written into the device.

L

H

L–H

During the data portion of a write sequence

:

CY7C1511KV18

− only the lower nibble (D

[3:0]

) is written into the device, D

[7:4]

remains unaltered.

CY7C1513KV18

− only the lower byte (D

[8:0]

) is written into the device, D

[17:9]

remains unaltered.

L

H

L–H During the data portion of a write sequence

:

CY7C1511KV18

− only the lower nibble (D

[3:0]

) is written into the device, D

[7:4]

remains unaltered.

CY7C1513KV18

− only the lower byte (D

[8:0]

) is written into the device, D

[17:9]

remains unaltered.

H

L

L–H

During the data portion of a write sequence

:

CY7C1511KV18

− only the upper nibble (D

[7:4]

) is written into the device, D

[3:0]

remains unaltered.

CY7C1513KV18

− only the upper byte (D

[17:9]

) is written into the device, D

[8:0]

remains unaltered.

H

L

L–H During the data portion of a write sequence

:

CY7C1511KV18

− only the upper nibble (D

[7:4]

) is written into the device, D

[3:0]

remains unaltered.

CY7C1513KV18

− only the upper byte (D

[17:9]

) is written into the device, D

[8:0]

remains unaltered.

H

H

L–H

No data is written into the devices during this portion of a write operation.

H

H

L–H No data is written into the devices during this portion of a write operation.

Write Cycle Descriptions

The write cycle description table for CY7C1526KV18 follows.

[2, 10]

BWS

0

K

K

L

L–H

During the data portion of a write sequence, the single byte (D

[8:0]

) is written into the device.

L

L–H

During the data portion of a write sequence, the single byte (D

[8:0]

) is written into the device.

H

L–H

No data is written into the device during this portion of a write operation.

H

L–H

No data is written into the device during this portion of a write operation.

Note

10. Is based on a write cycle that was initiated in accordance with the

Write Cycle Descriptions

table. NWS

0

, NWS

1

, BWS

0

, BWS

1

, BWS

2

,

and BWS

3

can be altered on

different portions of a write cycle, as long as the setup and hold requirements are achieved.
