Page 40
40
DVRT41 Direct Vent Gas Fireplace
10006740
DVRT41
(continued)
Ref.
Description
DVRT41
1.
Log Set DVRT41 (Complete)
10006185
1a.
Log Rear (G7)
10006798
1b.
Log Front Right (G6)
10006797
1c.
Log Front Left (G10)
10006801
1d.
Log Front Center (G9)
10006800
1e.
Log Crossover Left Top (G8)
10006799
2.
Volcanic Rock
20000376
3.
Lava Rock - Burner
57897
3a.
Platinum Embers
78037
4.
Bracket Rear Log Assembly Black
10006780
5.
Grate Assembly
10006332
6a.
Burner Housing Assembly - NG
10006177
6b.
Burner Housing Assembly - LP
10006395
7.
Ceramic Tile (Single)
57803
8.
Manifold Assembly
10003207
9.
Refractory CR Kit DVRT41
10006718
9a.
Refractory Lining Base Right
10006713
9b.
Refractory Lining Base Left
10006714
9c.
Refractory Lining Right
10006715
9d.
Refractory Lining Left
10006716
9e.
Refractory Lining Rear
10006717
10.
Glass with Gasket Assembly DVRT41
10006719
11.
Gasket Glass
10000992
12.
Window Assembly DVRT41
10006720
13.
Clamp Frame Window
54174
14.
Louvre Assembly Top
10000039
15.
Louvre Assembly Bottom
10000040
16.
Bottom Louvre Hinge
52356
17.
Deflector Top
54364
18.
Orifice Rear Burner - Nat. (not shown)
Refer to Rating Plate for Orifice Specifications
19.
Orifice Rear Burner - LP (not shown)
Refer to Rating Plate for Orifice Specifications
20.
Orifice Front Burner - Nat. (not shown)
Refer to Rating Plate for Orifice Specifications
21.
Orifice Front Burner - LP (not shown)
Refer to Rating Plate for Orifice Specifications
22.
Switch Rocker
53606
23.
Switch ON/OFF
51842
24a.
Valve - Honeywell VS8421 - Nat.
10001782
24b.
Valve - Honeywell VS8421 - LP
10001759
25a.
Valve - SIT 820 - Nat.
52677
25b.
Valve - SIT 820 - LP
52678
26a.
Pilot Assembly - SIT Top Conv. - Nat. (3 way)
10002264
26b.
Pilot Assembly - SIT Top Conv. - LP (3 way)
10002265
27.
Electrode Ignitor w/Cable
10001297
28.
Nut Electrode
57886
29.
Pilot Tube 1/8” x 24” Long w/Fittings (SIT Pilot)
10001296
