Page 10
6
Overview
Welch Allyn Connex CSK software
CP 100 and CP 200 configuration examples
Standalone configuration, removable media or wired
Client-server configuration, removable media or wired
or
CardioPerfect Workstation
Installation menu option: “Server”
Functional diagram:
“Software modules in a standalone CardioPerfect Workstation, removable media or wired”
USB cable
Server
Installation menu option:
“Server”
or
Workstation (client)
Installation menu option: “Client”
Functional diagram:
“Software modules in a client-server configuration, removable media or wired”
