CardioPerfect Webstation User Manual
DIR 80016200 Rev. A - 7 -
1. Resting ECG
1.1. Resting ECG - Getting started
This section will guide you around the various parts of the Welch Allyn CardioPerfect
Webstation Resting ECG module.
Search area The search area contains search and display functionality that lets you easily
retrieve patients and tests. In the search area, you can find a patient, see
which tests were recorded for that patient and see the kind of tests that were
recorded. You can also select search patterns, an easy way of finding
information that you need frequently.
Workspace The workspace is the core part of Welch Allyn CardioPerfect Webstation. It
displays the ECG in various formats. These formats, also called views, are
each displayed on a separate tab. The workspace is the place where you view,
compare and measure ECGs.
Parameters
area The parameters area contains some details of the ECG, such as the age and
the heart rate of the patient, and the global measurements for the ECG (P
Search
area
Parameters
area
Interpretation
area
Workspace
