Controls, indicators, and connectors
No. Feature Description
1 LCD screen 800 x 480 pixels color touchscreen provides a graphical user
interface.
2 Power switch and LED Power-on/Standby switch.
The LED indicates the charging status when connected to AC
power:
• Green: The battery is charged.
• Amber: The battery is charging.
3 Patient cable connector Provides connection for patient cable.
4 Printer Spirometry FVC report
Efforts:
•
All efforts: Prints all efforts.
• Three best efforts: Prints the three best efforts of each type
that was saved.
• Only the best effort: Prints only the best effort of each type
that was saved — best FVC, FVC-pre, FVC-post.
Note The printer also provides a printout of patient
Auto ECG, Stat ECG, or Rhythm ECG.
4 Introduction CP 150 spirometry option
