Directions for Use Program Mode 41
If PRN HEADER CUSTOM is selected, a line cursor will flash in the left-hand corner
below the words PRN HEADER CUSTOM. To “type” in the desired header, use the dB
HL knob. Rotating the knob clockwise will sequence you through the alphabet in the
forward direction and rotating this knob counterclockwise will sequence you through the
characters in a reverse direction. The available character set is: A -Z; 0 - 9; and a blank
space. A total of 35 character spaces are available. When the desired character is
displayed, press the
button to store it. The cursor will move into position for the next
character. Select the next character and press to store. When the custom header is
complete, press the PROG button to exit from the submenu. To change/delete a
previously saved character, press the
to position the cursor at that character. Use the
HL knob to select the new character to change or select the blank space to delete.
INTERNAL PRINTER/EXTERNAL PRINTER
These items toggle between either printing to the internal printer (4" paper) or sending the
information to an external printer. The external printer is connected through a USB port on
the back panel. The printer must be a DeskJet with PCL3 or PCL3GUI protocol.
To select the printer, move the cursor next to the Internal or External printer and press the
button to save the setting.
RESET TO DEFAULTS
This option will reset the programmable settings to the Welch Allyn factory defaults.
Note To center the header, consider the length of the name to be inserted and calculate
from the left margin where the header will begin. Type blank spaces to the start
point of the custom header.
M +
M +
Program Mode - Factory Default Settings
AUDIOMETRY RESULTS - PRINT - AUDIOGRAM
REFLEX RESULTS - REFLEX HL + CURVE
226 Hz Reflex - Ipsi 1000 Hz
NORMAL BOX - NORMAL BOX ASHA
AUDIOMETRY RANGE - AUD RANGE NORMAL
DEFAULT TRANSDUCER - DD45
PRINT HEADER - PRN HEADER WA
LANGUAGE - ENGLISH
DATA XFER CONFIG - 115.2 KBAUD
NO PARITY + 8-BIT
XON/XOFF DISABLED
POWER UP SETTING - TYMP REFLEX
PRINTER TYPE - INTERNAL PRINTER
AUTO HL SETUP
TEST FREQ (Hz) - 500 Hz
- 1000 Hz
- 2000 Hz
- 3000 Hz
