34 Program Mode Welch Allyn TM286 Auto Tymp
Program Menu Page 1 Option Descriptions
TYMP OPTIONS . . .
This submenu determines tympanogram display and test options.
NORMAL BOX ASHA/NORMAL BOX OFF
It is possible to have the Normal Box, as defined by ASHA, appear on the tympanogram
screen and printout. The boundaries for this Normal Box are -150 daPa to +100 daPa and
0.2 cm to 1.4 cm
3
.
NORMAL BOX ASHA is the factory default setting. To select the NORMAL BOX OFF,
move the cursor next to the selection and press the
button to save. Saved should
appear on the bottom right corner of the LCD and an “*” should appear next to the
NORMAL BOX OFF option to denote the selection.
REFLEX DISPLAY
Reflex test results can be displayed and printed in three different formats:
• Reflex dB HL plus curve
The default setting for this grouping is Reflex dB HL plus curve. All reflex test results will
appear on the display and printout with the following information:
a. I (Ipsilateral) selected
b. Frequency: 500, 1000, 2000, or 4000 Hz
c. Intensity level where response was detected
Note Pushing the Print button while in Program mode will print out the currently
programmed settings.
When navigating through the Program menu, features that are not available on
the purchased version of the TM286 will be represented by invalid on the LCD.
Factory Default settings are listed on page 41 .
NORMAL BOX ASHA BASELINE ON
(Not available on the TM286) 1k
NORMAL BOX OFF BASELINE OFF
(Not available on the TM286) 1k
NEWBORN NRM ON
(Not available on the TM286) 1k AUTOSTART ON
(Not available on the TM286) 1k
NEWBORN NRM OFF
(Not available on the TM286) 1k AUTOSTART OFF
(Not available on the TM286) 1k
50th PERCNT ON
(Not available on the TM286) 1k
50th PERCNT OFF
(Not available on the TM286) 1k
Note A compliance value of 1.5 cm
3
or greater will turn off the ASHA normal box
automatically.
