Page 4
Page 2 | 1-800-343-9463
MPS
033114
QUICK REFERENCE GUIDE
Wall Mounted Mini Split Evaporator Unit (Fan Coil Unit) Front / Side View
Evaporator Unit (Fan Coil Unit) Rear / Side View
Controller
Filter Grille
Evaporator Unit (Fan Coil Unit)
Circular Connection
Mounting Location
INSIDE CELLAR
Option 2
THROUGH THE WALL
Option 1
Knock Out For Wiring
Knock Out For Suction Line
Knock Out For Liquid Line
Knock Out For Drain Line
Knock Out For Wiring
Mounting Key Hole (X4)
Knock Out For Suction Line
Knock Out For Liquid Line
Knock Out For Drain Line
