Page 21
PPU-231 User’s Manual
8
CITIZEN
2.3.3
Printing Head and Paper Cutter Layout
Presenter Sensor Position
Approx. 90 mm
Paper Feed
Direction
Presenter Drive
Roller Position
Auto Cutter Position
Thermal Head Position (Printing Position)
Approx. 12 mm
Approx. 48 mm
Approx. 20 mm
Black Mark
(Back Side)
6
mm
1 0 m m 20 mm
