74 I-Class
Advanced Entry Calibration (continued)
Step Operator Action Displayed Message Comment
12 From the data collected in
Steps 10 and 11, where
both the sensor readings are
above 20, subtract each
Label Value from the
corresponding TOF Value.
These are the Difference
Values.
From the resulting list, find
the largest Difference
Value (see example below).
Its associated Gain Number
will provide the best
algorithm for your media.
HBJO!USBO!!!!!!=zzz?
+11!!!!!!!!!)1!.!42*
Or, for reflective media:
HBJO!SFGM!!!!!!=zzz?
+11!!!!!!!!!)1!.!42*
Both sensor
readings must
be above 20.
Gain
Number
Label
Value
TOF
Value
Difference
Value
00 255 254 1
01 251 240 11
02 241 213 28
03 231 182 49
04 219 150 69
05 212 119 93
06 200 88 112
07 189 58 131
08 178 32 146
09 167 19 N/A
10 156 17 N/A
11 146 16 N/A
12 136 15 N/A
… … … …
31 116 14 N/A
For example, if your
compiled data had the
values shown in this
table, Gain Number 8
would be chosen
because it has the
highest Difference
Value (146) where
both the Label Value
and the TOF Value
are above 20.
32 112 14 N/A
