I-Class 117
Appendix C
Module Assignments
Memory Module
Designator Module Size Volatile* Location / Use
A Future Option N/A N/A
B Future Option N/A N/A
D
1024 KB
(default size)
Yes Main PCB SDRAM – user addressable
for graphics, fonts, and label formats
F 4 MB No Optional Flash Card – user addressable
for graphics, fonts, and label formats
G 256 KB No Main PCB Flash – user addressable for
graphics, fonts, and label formats
(unavailable on the I-4206 and I-4208
models).
Y 64 KB No Main PCB Flash – reserved for EFIGS
Z 4 MB No Optional Flash Card – reserved for
ILPC
*When power is removed from the printer, stored data will be lost.
Print Resolutions and Maximum Label Widths
Resolutions and Widths
Maximum Print
Width
Model Printhead
Resolution
Inches Millimeters
Factory Default
Setting
I-4206, I-4208, &
I-4212
203 dots/inch
(8 dots/mm)
4.10 104 4.10
I-4308 300 dots/inch
(11.8 dots/mm)
4.16 105.7 4.16
I-4406 406 dots/inch
(16 dots/mm) 4.10 111.8 4.10
I-4604 600 dots/inch
(23.6 dots/mm)
4.16 108.2 4.16
