34 Tracer AV Installation Manual
6.3 Continuous Output (Stream) Format
Figure 6-1 shows the continuous output format sent from the Tracer AV Serial port to the Remote Display.
Note: In Setup mode, the text display message follows the following format: <100DM> or
<100DMText!>.
Figure 6-1. Continuous Output Data Format
ASCII 02
(decimal)
Weight data: 7 digits, right-justified, with
decimal point, l eading zer o s upr e ssion.
Overload = ^^^^^^^
Underrange = ] ] ] ] ] ] ]
Display overflow = OVERFL
LB = pounds
KG = kilogram
TN = ton
GM = grams
OZ = ounces
= none
G = Gross
N = Net
Status:
< space > = valid
I = Invalid
M = Motion
O = Over/under range
Polarity:
< space > = Positive
<–> = Negative
<^> = Overload
<]> = Underrange
or
ASCII 13, 10
(decimal)
Z = Center of zero
