11 BIOS Setup
Kontron User's Guide ETXexpress® CD 70
11.7.1 PCI Express Ports
Feature Option Description
PCI Express – Root Port 1
Disabled
Enabled
Auto
Control the PCI Express Port via this setup
option.
Disabled – Port always disabled.
Auto – Only enable if card found
Note that if Root Port 1 is disabled, Root
Ports 2-4 will be disabled as well.
PCI Express – Root Port 2
Disabled
Enabled
Auto
PCI Express – Root Port 3
Disabled
Enabled
Auto
PCI Express – Root Port 4
Disabled
Enabled
Auto
PCI Express – Root Port 5
Disabled
Enabled
Auto
PCI Express – Root Port 6
Disabled
Enabled
Auto
PCI Hot-Plug Resources
Disabled
Enabled
Enabled/Disable Hot-Plug support
Root Port ASPM Support
Disabled
Auto
Control ASPM support for all the enabled
Root Ports.
Auto = will set ASPM to the highest common
supported ASPM between the Port and
Endpoint.
Monitor PCIExpress Init
Disabled
Enabled
If enabled this control enables the watchdog
during PCIexpress init.
Delay before PCIe Init
Disabled
Enabled
If enabled this control activates a short
delay just before initializing PCIexpress
devices
Renew LAN regs from EEPROM
Disabled
Enabled
If enabled the LAN registers are re-read from
EEPROM during POST
