9 System Ressources
Kontron User's Guide ETXexpress® CD 46
9.3 Memory Area
Upper Memory Used for Available Comment
C0000h – CFFFFh VGA BIOS No
D0000h – DDFFFh Yes shadow RAM (ISA bus restriction)
DE000h – DFFFFh USB registers No
E0000h – FFFFFh System BIOS No
9.4 I/O Address Map
The I/O-port addresses of the COMe-bCD2 are functionally identical with a standard PC/AT.
The following I/O ports are additionally used:
I/O Address Used for Available Comment
2e-2fh
Winbond external
I/O controller
No Available if external I/O controller not used.
4e-4fh TPM No Available if TPM not populated.
2F8-2FFh COM1 No Available if device is disabled in setup
3F8-3FFh COM2 No Available if device is disabled in setup
1000h > PCI No
I/O ports 1000h and above might be allocated by PCI devices or
onboard hardware.
9.5 Peripheeral Component Interconnect (PCI) Devices
PCI Device Busmaster PCI Interrupt Comment
Audio, USB
and Ethernet
See IRQ
resource tables
above
Integrated in the Intel chipset. No REQx/GNTx
pair needed.
Note: You can use REQ0/GNT0, REQ1/GNT1, REQ2/GNT2, and REQ3/GNT3 pairs for external PCI devices.
9.6 Inter IC (I 2 C) Bus
I2C Address Used For Available Comment JIDA-Bus-Nr.
A0h JIDA-EEPROM No EEPROM for CMOS data. 0
A2h JIDA-EEPROM No 0
B0h WD-PIC No Reserved for internal use. 0
