3 Specifications
Kontron User's Guide ETXexpress® CD 14
PCI Express: Intel® ICH7M-DH
5 PCI Express x1 lanes
Optionally 1 x4 lane and 1 x1 lane is possible by strapping option on the baseboard.
(see 2.2.2) To use this feature please pull-up AC_SYNC (A29) and AC_SDOUT (A33) to
3.3V.
PCI 32: Intel® ICH7M-DH
Parallel PCI Bus 32 bit 33 MHz
Low Pincount Bus (LPC): Intel® ICH7M-DH
Enhanced Intelligent Drive Electronics (EIDE): Intel® ICH7M-DH
One PCI Bus Master IDE port
Supports 2 IDE devices
Ultra 100 Direct Memory Access (DMA) mode
Programmed Input/Output (PIO) modes up to Mode 4 timing
Multiword DMA Mode 0,1,2 with independent timing
Serial ATA: Intel® ICH7M-DH
2 Channels Serial ATA
SATA Spec. Rev. 1.0 up to 150 MB/s per channel
SATA II (AHCI)
Supports RAID level 0 and 1
Universal Serial Bus: Intel® ICH7M-DH
8 USB 1.1/2.0 ports (UHCI and EHCI)
USB legacy keyboard support
USB floppy, CD-ROM, Hard drive, and memory stick boot support
Gigabit Ethernet: Realtek RTL8111B/C 10/100/1000
Fully compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Onboard video graphics array (VGA): Intel® 945GM/GME:
Intel® Gen 3.5 Graphics engine
Dynamic Video Memory Technology (DVMT 3.0)
Cathode ray tube (CRT) up do QXGA
low voltage differential signaling (LVDS) liquid-crystal display (LCD) and SDVO
interfaces up to UXGA
Supports DX 9.1
