9 System Ressources
Kontron User's Guide ETXexpress® CD
47
9.7
System Managment (SM) Bus
Following SM bus addresses are reserved.
SM Bus Address
SM Device
Comment
JIDA-Bus-Nr.
10h
SMB Host
Do not use under any circumstances.
1
12h
SMART_CHARGER
Not to be used with any SM bus device except a charger
1
14h
SMART_SELECTOR
Not to be used with any SM bus device except a selector
1
16h
SMART_BATTERY
Not to be used with any SM bus device except a battery
1
30h
HW-Monitor
Can be used when there is no external SuperI/O
1
5Ch
HW-Monitor
Can be used when there is no external SuperI/O
1
A0h
SPD
SDRAM EEPROM
1
D2h
Clock generator
Do not use under any circumstances.
1
D4
Clockgenerator
Do not use under any circumstances
1
The standard COMe-bCD2 Power management BIOS supports the Smart Battery System M.A.R.S. If you
require further information about this topic, please contact Kontron Embedded Modules GmbH Technical
Support.
9.8
JILI I
2
C Bus
I2C Address
Used For
Available
Comment
JIDA-Bus-Nr.
A0h
JILI-EEPROM
No
EEPROM for JILI-Data
2
62h
Brightness control No
MAX536262
2
