4 Connector Pinouts
Kontron User's Guide ETXexpress® CD 30
250MHz core render clock and 200 MHz core display clock at 1.05V core voltage
Supports TV-out, LVDS, CRT and SDVO
Dynamic Video Memory Technology (DVMT 3.0)
2D graphics engine
3D graphics engine
3D setup and render engine
Zone rendering
High quality performance texture engine
Viewpoint transform and perspective divide
Max. resolution CRT: QXGA 2048x1536
Max. resolution LCD: UXGA 1600x1200 (4G colors)
Bits/Pixels supported on LCD: 1x18 bit, 2x18 bit, 1x24 bit, 2x24 bit
Note: The 945GM/GME does not support 24 bit LVDS but emulates the missing 2 bits per color and most of the
panels can be used with this limitation. SDVO supports full 24 bit.
Configuration
The graphics controller requires the following resources:
An IRQ
Several I/O addresses
Memory-address blocks in high memory
The BIOS allocates the resources during AGP configuration. Many resources are set for compatibility with
industry-standard settings.
4.3.7 LVDS Flat Panel Interface (JILI)
The user interface for flat panels is the JUMPtec Intelligent LVDS Interface (JILI). The implementation of
this subsystem complies with the COM Express® Specification. Implementation information is provided
in the COM Express® Design Guide. Refer to the documentation for additional information.
4.3.8 Digital Flat Panel Interface (JIDI)
The COMe-bCD2 does not support the JUMPtec Intelligent Digital Interface (JIDI).
4.3.9 Ethernet
The Ethernet interface is based on the Realtek RTL8111b/c Gigabit Ethernet PCIexpress controller. This
PCIexpress controller is a fully integrated 10/100/1000BASE-TX LAN solution.
The Ethernet interface requires an external transformer. See the COM Express® Design Guide for
suggestions on transformer selection.
