KTQM77 – KTHM76 Users Guide
KTD-N0850-F Page 7
Introduction
This manual describes the KTQM77 family consisting of the KTQM77/mITX and the KTHM76/mITX
boards made by KONTRON Technology A/S. In this Users Guide the boards will in general also be
denoted KTQM77 and KTHM76 and if a subject is not depending on exact board type then both types of
board will be denoted KTQM77.
The KTQM77 and KTHM76 boards are based on the QM77 and HM76 chipset respectively and support
3 rd generation Intel® i7 -, i5 -, i3 2Core and 4Core mobile processors. See “Processor Support Table for
more specific details.
The KTQM77 family consist on members having same form factors, and the same functionality except
for the functions listed in the table below.
KTQM77 variants LAN
IEEE
1394a
RAID AMT eDP
PCIe x16
Bifurcation USB
KTQM77/mITX 3x 2x 0/1/5/10 AMT8.0 Yes Yes
4x USB3.0/2.0
10x USB2.0
KTHM76/mITX 1x No No No No No
4x USB3.0/2.0
8x USB2.0
Use of this Users Guide implies a basic knowledge of PC-AT hard- and software. This manual is
focused on describing the KTQM77 board’s special features and is not intended to be a standard PC-AT
textbook.
New users are recommended to study the short installation procedure stated in the following chapter
before switching-on the power.
All configuration and setup of the CPU board is either done automatically or manually by the user via
the BIOS setup menus. Only exception is the “Load Default BIOS Settings” Jumper.
