Document revision history.
Revision Date By Comment
F Jan 2 nd 2014 MLA
CPU list revised. BIOS part upgraded in according to BIOS
Revision Release note (KTQM7715.bin). Added KTHM76/mITX.
E Jun13th 2013 MLA Minor corrections.
D June 4 th 2013 MLA
Correction to AMT 8.0. Updated CPU list and RAM List. Several
corrections.
C May 27 th 2013 MLA
Added AMT short description. Correction to eDP and LVDS text.
BIOS Recover text upgraded. Added note for PCIex2 support.
BIOS information upgraded to BIOS 14.
B Mar. 6 th 2013 MLA
Page 67 corrected function name. Added to BIOS section:
System Temperature Ext Type and Fan limits. Added cable kits.
Corrected PCIex1 signals. Note on OS installation via USB.
A Feb. 19 th 2013 MLA
Removed 5V tolerance for some GPIO’s. Jumper J37 info
changed. 3.3V now 5% tolerance. Improved 12V only
description. Updated CPU list. Revision of BIOS section.
Completed System Resources.
0 July 10 th 2012 MLA Preliminary version
