KTQM77 – KTHM76 Users Guide
KTD-N0850-F Page 10
2 System Specification
2.1 Component main data
The table below summarizes the features of the KTQM77/mITX embedded motherboard.
Form factor KTQM77/mITX and KTHM76/mITX: miniITX (170,18 mm by 170,18 mm)
Processor Support 2 nd and 3 rd Generation Intel® Core™ (Sandy Bridge M and Ivy Bridge M
respectively) and Intel® Celeron® processors via Socket G2 (rPGA 988B ) ZIF Socket
• Intel® Core™ i7
• Intel® Core™ i5
• Intel® Core™ i3
• Intel® Celeron® B810
Up to 1333MHz system bus and 2/3/4/6MB internal cache.
Memory • DDR3 SODIMM 204pin socket (2 sockets)
• Support single and dual ranks DDR3 1066/1333/1600MT/s
(PC3-8500/PC3-10600/PC3-12800)
• Support system memory from 256MB and up to 2x 8GB.
Notes:Less than 4GB displayed in System Properties using 32bit OS
(Shared Video Memory/PCI resources is subtracted)
• ECC not supported (PGA processors do not support ECC)
Chipset Intel QM77 /HM77 PCH (Platform Controller Hub)
• Intel ® VT-d (Virtualisation Technology for Directed I/O)
• Intel ® TXT (Trusted Execution Technology)
• Intel ® vPRO (KTQM77 only)
• Intel ® AMT (Active Management Technology) version 8.0 (KTQM77 only)
• Intel ® AT (Anti-Theft Technology)
• Intel ® HD Audio Technology
• Intel ® RST (Rapid Storage Technology)
• Intel ® RRT (Rapid Recover Technology)
• SATA (Serial ATA) 6Gb/s and 3Gb/s.
• USB revision 2.0
• USB revision 3.0
• PCI Express revision 2.0
• ACPI 3.0b compliant
• Dual or Triple Display support (Dual/Triple Graphic Pipes, depends on CPU)
• Blue-ray HD video playback
Security • Intel® Integrated TPM 1.2 support
Management • Intel® Active Management Technology (Intel® AMT) 8.0 (KTQM77 only)
Audio Audio, 7.1 Channel High Definition Audio Codec using the VIA VT1708S codec
• Line-out
• Line-in
• Surround output: SIDE, LFE, CEN, BACK and FRONT
• Microphone: MIC1 and MIC2
• CDROM in
• SPDIF (electrical Interface only)
• On-board speaker (Electromagnetic Sound Generator like Hycom HY-05LF)
System Specification
