KTQM77 – KTHM76 Users Guide
KTD-N0850-F Page 11
Video Intel i3, i5 & i7 3 rd Generation Mobile processors support Intel HD Graphics 4000.
Intel i3, i5 & i7 2 nd Generation Mobile processor supports Intel HD Graphics 3000.
Intel Celeron Processor B810 supports Intel HD Graphics.
eDP (Embedded DisplayPort) directly from processor. (KTQM77 only).
Analogue VGA and digital display ports (DVI, 2x DP, LVDS) via the Mobile Intel ®
QM77 Chipset.
• VGA (analogue panel) via DVI-I (sharing DVI-I connector with DVI-D)
• DVI-D (sharing DVI-I connector with analogue VGA)
• 2x DP (DisplayPorts), comply with DisplayPort 1.2 specification.
• LVDS panel support up to 24 bit, 2 pixels/clock and 1920x1200.
• HDMI panel support via DP to HDMI Adapter Converter.
• Second VGA panel support via DP to VGA Adapter Converter.
• Second DVI panel support via DP to DVI Adapter Converter.
• Dual independent pipes for Mirror and Dual independent display support
(exception is combination LVDS and eDP)
• Triple independent pipes (Intel HD Graphics 4000 only) for triple independent or
cloned displays are supported from OS. Any 3 displays via DP0, DP1, DVI-D or
DVI-A, LVDS or eDP can be used, but only active DP to DVI/HDMI converters can
be used.
I/O Control Via ITE IT8516E Embedded Controller and Nuvoton W83627DHG I/O Controller (both
via LPC Bus interface)
Peripheral
interfaces
• Two USB 2.0 ports on I/O area
• Four USB 3.0 / USB 2.0 on I/O area
• Eight USB 2.0 ports on internal pinrows (KTQM77 only)
• Six USB 2.0 ports on internal pinrows (KTHM76 only)
• Two IEEE 1394a-2000 (up to 400M bits/s) on internal pinrows (KTQM77 only)
• Four Serial ports (RS232) on internal pinrows
• Two Serial ATA-600 IDE interfaces
• Four Serial ATA-300 IDE interfaces
• RAID 0/1/5/10 support (KTQM77 only)
• mSATA via mPCIe_0 connector
• PS/2 keyboard and mouse ports via pinrow
LAN
Support
• 1x 10/100/1000Mbits/s LAN (ETHER1) using Intel® Lewisville 82579LM Gigabit
PHY connected to QM77 supporting AMT 8.0 (AMT only on KTQM77)
• 2x 10/100/1000Mbits/s LAN (ETHER2/ETHER3)using Intel® Hartwell 82574L PCI
Express controllers (KTQM77 only)
• PXE Netboot supported.
• Wake On LAN (WOL) supported
Expansion
Capabilities
• PCI-Express slot(s):
o 1 slot PCIe x16 (PCIe 2.0 and up to PCIe 3.0 when using Ivy Bridge CPU)
o 1 slot PCIe x1 (PCIe 2.0):
o 1 slot miniPCI-Express (PCI Express or mSATA signals, no USB signals)
o 1 slot miniPCI-Express (PCI Express signals, no mSATA or USB signals)
• SMBus, compatible with ACCES BUS and I2C BUS, (via Feature connector)
• SPI bus routed to SPI connector
• DDC Bus routed to DVI-I connector
• 18 x GPIOs (General Purpose I/Os), (via Feature connector)
• DAC, ADC, PWM and TIMER (Multiplexed), (via Feature connector)
• WAKE UP / Interrupt Inputs (Multiplexed), (via Feature connector)
• 3 Wire Bus for GPIO Expansion (up to 152 GPIOs), (via Feature connector)
• 8 bit Timer output, (via Feature connector)
System Specification
