10.3.2.5 Memory Thermal Configuration
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Chipset
Memory Thermal Configuration
Memory Thermal Management
PECI Injected Temperature
EXTTS# via TS-on-Board
EXTTS# via TS-on-DIMM
Virtual Temperature Sensor (VTS)
[Enabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
Enable or disable Memory
Thermal Management.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1226. Copyright © 2012 American Megatrends, Inc
Function Selection Description
Memory Thermal
Management
Disabled
Enabled
Enable or disable Memory Thermal
Management.
PECI Injected Temperature
Enabled
Disabled Enable or disable memory temperatures to be
injected to the processor via PECI.
EXTTS# via TS-on-Board
Enabled
Disabled
Enable or disable routing TS-on-Board to be
injected to EXTTS# pins on the PCH.
EXTTS# via TS-on-DIMM
Enabled
Disabled
Enable or disable routing TS-on-DIMM to be
injected to pin on the PCH.
Virtual Temperature
Sensor (VTS)
Enabled
Disabled
Enable or disable Virtual Temperature Sensor
(VTS).
BIOS - Chipset
