Kontron KTHM76-mITX - Manual (Page 23)

KTQM77 – KTHM76 Users Guide
KTD-N0850-F Page 23
a) Low Power Setup KTQM77/mITX ATX+12V PSU TBD
DOS Idle, Mean, No external load
Supply
Current draw
[A]
Power consumption
[W]
+12V 0,140 1,680
+12V P4 1,222 14,664
+5V 0,411 2,055
+3V3 0,557 1,838
-12V 0,035 0,42
5VSB 0,007 0,035
Total 20,7
Windows 7, mean
3DMARK2005 ( first scene ) & BiT 6
Supply
Current draw
[A]
Power consumption
[W]
+12V 0,165 1,980
+12V P4 3,250 39,000
+5V 0,450 2,250
+3V3 0,577 1,904
-12V 0,046 0,552
5VSB 0,007 0,035
Total 45,7
S0 Mode, Mean, No external load
Supply
Current draw
[A]
Power consumption
[W]
+12V 0,107 1,284
+12V P4 0,510 6,120
+5V 0,336 1,680
+3V3 0,576 1,901
-12V 0,043 0,516
5VSB 0,007 0,035
Total 11,5
S3 Mode, Mean, No external load
Supply
Current draw
[A]
Power consumption
[W]
5VSB 0,218 1,090
Total 1,09
S5 Mode, Mean, No external load
Supply
Current draw
[A]
Power consumption
[W]
5VSB 0,213 1,065
Total 1,07
