8.7.3 Advanced Chipset Settings – SouthBridge Configuration
BIOS SETUP UTILITY
Chipset
South Bridge Chipset Configuration
USB Functions [10 USB Ports]
USB 2.0 Controller [Enabled]
HAD Controller [Enabled]
Audio Jack Sensing [Auto]
SMBUS Controller [Enabled]
SLP_S4# Min. Assertion Width [Disabled]
Restore on AC Power loss [Last State]
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
v02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature
Options Description
USB Functions Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
Disabled
2 USB Ports, USB0/1
4 USB Ports, USB0/1/2/3
6 USB Ports, USB0/1/2/3/4/5
8 USB Ports, USB0/1/2/3/4/5/6/7
10 USB Ports, all USB ports
USB 2.0 Controller Enabled
Disabled
Disabled only possible if less than 10USB Ports
are selected above.
HDA Controller Enabled
Disabled
Enabled
Disabled
Audio Jack Sensing Auto
Disabled Auto: The insertion of audio jacks are auto
determined.
Disabled: Driver assumes that all jacks are
inserted (usefull when using Audio pinrow).
SMBUS Controller Enabled
Disabled
Enabled (for all known OS at present time)
Disabled (only if required by OS etc.)
SLP_S4# Min. Assertion
Width
Disabled
4 to 5 seconds
3 to 4 seconds
2 to 3 seconds
1 to 2 seconds
Extra delay before turning on/off on board power
system when leaving/entering S4 (power down
state, Suspend to disk).
Restore on AC Power loss Power Off
Power On
Last State
Power Off
Power On
Last State
