3 kt965/atxe, Kt965 family – Kontron KT965 Series User Manual
Page 28
KT965 Family
KTD-00699-S
Public User Manual
Date: 2010-04-15 Page
28 of 90
4.1.3 KT965/ATXE
COM1
CRT
MSE
KBD
AUDIO
STACK
ETHER1
USB0
USB2
CDROM
USB8
USB9
USB6
USB7
ETHER2
USB4
USB5
SATA0 SATA1 SATA2 SATA3 SATA4 SATA5
ATX/ BTXPWR
SPI
Clr-CMOS
PCI Slot 1
PCIe x16
/ SDVO
COM2
FAN_SYS
KBDMSE
ATX+12V
FRONTPNL
AUDIO HEAD
FEATURE
TPM
DDR2 SLOT 4
DDR2 SLOT 3
DDR2 SLOT 2
DDR2 SLOT 1
PCI Slot 2
PCI Slot 3
PCI Slot 4
PCIe x4
(in x16 socket )
FAN_CPU
PCI Slot 5
PRINTER
