KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 68 of 90
8.3.3 Advanced settings – LAN Configuration
BIOS SETUP UTILITY
Advanced
LAN Configuration
ETH1 Configuration (Right) [Enabled]
MAC Address : 00E0F4000001 100MB *
ETH2 Configuration (Left) [Enabled]
MAC Address : 00E0F4000002 -
Control of Ethernet
Devices and PXE boot
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
v02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
* If link then speed is displayed (10Mb, 100Mb or 1000Mb)
Feature
Options Description
ETH1 Configuration Disabled
Enabled
With RPL/PXE boot Select if you want to enable the LAN adapter, or
if you want to activate the RPL/PXE boot rom
ETH2 Configuration Disabled
Enabled
With RPL/PXE boot Select if you want to enable the LAN adapter, or
if you want to activate the RPL/PXE boot rom
Note: Wake On Lan is always supported in BIOS, but OS has to setup support for wake after Shutdown for
relevant LAN port.
