KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 32 of 90
4.5 PCI-Express Connectors
The KT965 boards contains one 16-lane (x16) PCI Express port intended for an external PCI Express
graphics card. The PCI Express port is compliant to the PCI Express* Base Specification revision 1.1. The
x16 port operates at a frequency of 2.5 Gb/s on each lane while employing 8b/10b encoding; the port
supports a maximum theoretical bandwidth of 40 Gb/s in each direction. The PCI Express (x16) interface is
multiplexed with the SDVO ports.
Depending on the board variant the KT965 boards further supports one 4-lane (x4) PCI Express port.
The KT965/Flex supports one 16-lane (x16) PCI Express port and one 4-lane PCI Express (x16) port.
The KT965/ATXP supports one 16-lane (x16) PCI Express port.
The KT965/ATXE supports one 16-lane (x16) PCI Express port and one 4-lane PCI Express (x16) port.
4.5.1 PCI-Express x16/ SDVO connector
The KT965 boards supports one 16-lane (x16) PCI Express port for external PCI Express based graphics
boards or ADD2 devices.
Note Type Signal PIN Signal Type Note
+12V B1 A1 NC
+12V B2 A2 +12V
+12V B3 A3 +12V
GND B4 A4 GND
SMB_CLK B5 A5 NC
SMB_DATA B6 A6 NC
GND B7 A7 NC
+3V3 B8 A8 NC
NC B9 A9 +3V3
SB3V3 B10 A10 +3V3
WAKE# B11 A11 RST#
NC B12 A12 GND
GND B13 A13 PCIE_x16 CLK
PEG_TXP[15] / SDVOB_RED B14 A14 PCIE_x16 CLK#
PEG_TXN[15] / SDVOB_RED# B15 A15 GND
GND B16 A16 PEG_RXP[15] / SDVO_TVCLKIN
SDVO_CTRLCLK B17 A17 PEG_RXN[15] / SDVO_TVCLKIN#
GND B18 A18 GND
PEG_TXP[14] / SDVOB_GREEN B19 A19 NC
PEG_TXN[14] / SDVOB_GREEN# B20 A20 GND
GND B21 A21 PEG_RXP[14] / SDVOB_INT
GND B22 A22 PEG_RXN[14] / SDVOB_INT#
PEG_TXP[13] / SDVOB_BLUE B23 A23 GND
PEG_TXN[13] / SDVOB_BLUE# B24 A24 GND
GND B25 A25 PEG_RXP[13] / SDVO_FLDSTALL
GND B26 A26 PEG_RXN[13] / SDVO_FLDSTALL#
PEG_TXP[12] / SDVOB_CLKP B27 A27 GND
PEG_TXN[12] / SDVOB_CLKN B28 A28 GND
GND B29 A29 PEG_RXP[12]
NC B30 A30 PEG_RXN[12]
SDVO_CTRLDATA B31 A31 GND
GND B32 A32 NC
PEG_TXP[11] / SDVOC_RED B33 A33 NC
PEG_TXN[11] / SDVOC_RED# B34 A34 GND
GND B35 A35 PEG_RXP[11]
GND B36 A36 PEG_RXN[11]
PEG_TXP[10] / SDVOC_GREEN B37 A37 GND
PEG_TXN[10] / SDVOC_GREEN# B38 A38 GND
GND B39 A39 PEG_RXP[10] / SDVOC_INT
GND B40 A40 PEG_RXN[10] / SDVOC_INT#
PEG_TXP[9] / SDVOC_BLUE B41 A41 GND
PEG_TXN[9] / SDVOC_BLUE# B42 A42 GND
GND B43 A43 PEG_RXP[9]
GND B44 A44 PEG_RXN[9]
PEG_TXP[8] / SDVOC_CLKN B45 A45 GND
PEG_TXN[8] / SDVOC_CLKP B46 A46 GND
GND B47 A47 PEG_RXP[8]
