KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 31 of 90
4.4 Display Connectors
The KT965 board family provides onboard Analog CRT interface. Addtionally the KT965 boards provides
support for ADD2 cards through the onboard PCI Express x16 connector, with extension capability for
support of DVI, LVDS, VGA, HDMI/UDI, TV-Out, etc.
If a PCI Express x16 Graphics add-in card is used, the onboard Graphics controller (GMA 3000) is disabled.
4.4.1 CRT Connector (CRT)
Note
Pull
U/D Ioh/Iol Type Signal
PIN
Signal Type Ioh/Iol
Pull
U/D Note
6 GND PWR - -
/75R * A0 RED 1 11 NC - - -
7 GND PWR - -
/75R * A0 GREEN 2 12 DDCDAT IO TBD 2K2
8 GND PWR - -
/75R * A0 BLUE 3 13 HSYNC O TBD
9 5V PWR - - 1
- - - NC 4 14 VSYNC O TBD
10 GND PWR - -
- - PWR GND 5 15 DDCCLK IO TBD 2K2
Note 1:
The 5V supply in the CRT connector is fused by a 1.1A reset-able fuse.
Signal Description - CRT Connector:
Signal Description
HSYNC CRT horizontal synchronization output.
VSYNC CRT vertical synchronization output.
DDCCLK Display Data Channel Clock. Used as clock signal to/from monitors with DDC interface.
DDCDAT Display Data Channel Data. Used as data signal to/from monitors with DDC interface.
RED Analog output carrying the red color signal to the CRT. For 75 Ohm cable impedance.
GREEN Analog output carrying the green color signal to the CRT. For 75 Ohm cable impedance.
BLUE Analog output carrying the blue color signal to the CRT. For 75 Ohm cable impedance.
DIG-GND Ground reference for HSYNC and VSYNC.
ANA-GND Ground reference for RED, GREEN, and BLUE.
