Page 26: Connector layout
KT965 Family
KTD-00699-S
Public User Manual
Date: 2010-04-15 Page
26 of 90
4.1
Connector layout
4.1.1 KT965/Flex
COM1
CRT
MSE
KBD
AUDIO
STACK
ETHER1
USB0
USB2
CDROM
USB8
USB9
USB6
USB7
ETHER2
USB4
USB5
SATA0 SATA1 SATA2 SATA3 SATA4 SATA5
PCIe x4
ATX/ BTXPWR
SPI
Clr-CMOS
PCI Slot 2
PCIe x16
/ SDVO
FAN_SYS
KBDMSE
FRONTPNL
AUDIO HEAD
FEATURE
TPM
DDR2 SLOT 4
DDR2 SLOT 3
DDR2 SLOT 2
DDR2 SLOT 1
FAN_CPU
PCI Slot 1
ATX+12V
COM2
PRINTER
