KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 11 of 90
3. System specification
3.1 Component main data
The table below summarises the features of the KT965/Flex, KT965/ATXP and KT965/ATXE embedded
motherboards.
Form factor KT965/Flex: Flex-ATX (190,50millimeters by 228,60millimeters)
KT965/ATXP: ATX (190,50millimeters by 304,00millimeters)
KT965/ATXE: ATX (190,50millimeters by 304,00millimeters)
Processor
• Support for Intel® Core™2 Quad, Intel® Core™2 Duo, Intel® Pentium® 4 and the
Intel® Celeron® D in LGA775 package with up to 1066MHz system bus and
1/2/4/8MB internal cache.
• Support for Conroe (65 nanometer) and Cedar Mill (65 nanometer) family processors.
Memory
• 4 pcs DDR2 DIMM 240pin DRAM sockets.
• Support for DDR 533/667/800MHz (PC2-4200/PC2-5300/PC2-6400)
• Support system memory from 512MB and up to 4GB (*) (32 bit OS) / 8GB (64 bit OS).
(*) Only approx. 3GB displayed in System Properties.
(Shared Video Memory is withdrawn).
• ECC not supported
Chipset Intel Q965 Chipset consisting of:
• Intel® 82Q965 Graphics Memory Controller Hub (GMCH)
• Intel® ICH8DO I/O Controller Hub (ICH8DO)
Video
• Intel® GMA 3000 graphics engine
• Dynamic Video Memory Technology (DVMT 4.0), allowing up to 256MB dynamically
allocated Video Memory (System memory is allocated when it is needed).
• Analog Display Support CRT, 400-MHz, 24 bit integrated RAMDAC with support for
analogue monitors up to 2048x1536 at 75 Hz
• Single or dual channel 24bit LVDS panel support (OpenLDI/ SPWG) up to UXGA
(1600x1200) panel resolution supported by using ADD2 / SDVO cards. Interlaced
Display output support.
• Serial Digital Video Out (SDVO) ports (2 channels) for additional CRT, LVDS panel,
DVI, TV-Out and/or HDMI support via Advanced Digital Display 2 (ADD2) cards or
Media Expansion Cards.
• Dual independent pipe support, Mirror and Dual independent display support
Dual Monitor support with combinations of SDVO port devices and onboard CRT
Audio Audio, 7.1 and 7.2 Channel High Definition Audio Codec using the Realtek ALC882 codec
• Line-out
• Line-in
• Surround output: SIDE, LFE, CEN, BACK and FRONT
• Microphone:
MIC1
• CDROM in
• SPDIF Interface
Onboard speaker
(continues)
