KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 85 of 90
8.7.1 Advanced Chipset Settings – North Bridge Chipset Configuration
BIOS SETUP UTILITY
Chipset
North Bridge Chipset Configuration
Memory Remap Feature [Enabled]
PCI MMIO Allocation : 4GB To 2816MB
DRAM Frequency [Auto]
Configure DRAM Timing by SPD [Enabled]
Memory Hole [Disabled]
Initate Graphic Adapter [PEG/PCI]
Internal Graphics Mode Select [Enabled,8MB]
► Video Function Configuration
ENABLE: Allow remapping of
overlapped PCI memory
above the total physical
memory
DISABLE: Do not allow
remapping of memory
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
v02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature
Options Description
Memory Remap Feature Enabled
Disabled
ENABLE: Allow remapping of overlapped PCI
memory above the total physical memory
DISABLE: Do not allow remapping of memory
DRAM Frequency Auto
533 MHz
677 MHz
800 MHz
1067 MHz
Auto
533 MHz
677 MHz
800 MHz
1067 MHz
Configure DRAM Timing by
SPD Enabled
Disabled Enabled
Disabled
Memory Hole
[Disabled]
[Disabled]
15MB-16MB [Disabled]
15MB-16MB
Initate Graphic Adapter IGD
PCI/IGD
PCI/PEG
PEG/IGD
PEG/PCI Select which graphics controller to use as the
primary boot device.
Internal Graphics Mode
Select Disabled
Enabled, 1MB
Enabled, 8MB Select the amount of system memory used by the
Internal graphics device.
