Kontron KT965 Series - Manual (Page 63)

KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 63 of 90
8. BIOS Configuration / Setup
8.1 Introduction
The BIOS Setup is used to view and configure BIOS settings for the KT965 board. The BIOS Setup is
accessed by pressing the DEL key after the Power-On Self-Test (POST) memory test begins and before the
operating system boot begins. The Menu bar look like this:
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
The available keys for the Menu screens are:
Select Menu: <←> or <→>
Select Item: <↑> or <↓>
Select Field:
Change Field: <+> or <->
Help:
Save and Exit:
Exits the Menu:
Please note that in the following the different BIOS Features will be described as having some options.
These options will be selected automatically when loading either Failsafe Defaults or Optimal Defaults. The
Default options will be indicated by the option in bold, but please notice that when Failsafe Defaults are
loaded a few of the options, marked with “*”, are now the default option.
8.2 Main Menu
BIOS SETUP UTILITY
Main
Advanced PCIPnP Boot Security Chipset Exit
System Overview
AMIBIOS
Version : 08.00.14
Build Date: 03/04/08
ID : KT965017
PCB ID : A1
Serial # : 00478603
Part # : 61310000
Processor
Intel® Core (TM)2 CPU 6700 @ 2.66GHz
Speed : 2666MHz
Count : 1
System Memory
Size : 1016MB
System Time [10:18:15]
System Date [10/19/2009]
Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a field.
Use [+] or [-] to
configure system Time.
<- Select Screen
|| Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Main Menu Selections
You can make the following selections. Use the sub menus for other selections.
Feature
Options Description
System Time HH:MM:SS Set the system time.
System Date MM/DD/YYYY Set the system date.
