KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 23 of 90
KT965/Flex board mounted w/ 2.13GHz Core Duo & 1GB DDR2 Ram test results:
Test Supply Current draw Power consumption
+12V 1.51A 18.12W
+5V 1.48A 7.4W
+3V3 2.86A 9.44W
-12V 0.004A 0.05W
5VSB 0A 0W
DOS, Idle, mean
Total 35W
+12V 4.35A 52.2W
+5V 2.05A 10.25W
+3V3 5.11A 16.83W
-12V 0.004A 0.05W
5VSB 0A 0W
WinXP, 3DMARK2000 &
CPUBURN, mean
Total 79.36W
+12V 4.64A 55.68W
+5V 2.24A 11.2W
+3V3 5.47A 18.05W
-12V 0.004A 0.05W
5VSB 0A 0W
WinXP, 3DMARK2000 &
CPUBURN, peak
Total 84.98W
+12V 2.64A 31.68W
+5V 1.31A 6.55W
+3V3 2.66A 8.78W
-12V 0.004A 0.05W
5VSB 0A 0W
S1, mean
Total 47.06W
+12V 0A 0W
+5V 0A 0W
+3V3 0A 0W
-12V 0A 0W
5VSB 0.21A 1.05W
S3, mean
Total 1.05W
+12V 0A 0W
+5V 0A 0W
+3V3 0A 0W
+-12V 0A 0W
5VSB 0.21A 1.05W
S4, mean
Total 1.05W
+12V 6.88A
+5V 1.92A
+3V3 3.28A
-12V 0.08A
Inrush, peak
5VSB 3.6A
