KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 75 of 90
8.3.10 Advanced settings – Remote Access Configuration
BIOS SETUP UTILITY
Advanced
Configure Remote Access type and parameters
Remote Access [Enabled]
Serial port number [COM1]
Base Address, IRQ [3F8h, 4]
Serial Port Mode [115200 8,n,1]
Flow Control [None]
Redirection After BIOS POST [Always]
Terminal Type [ANSI]
Select Remote Access
type.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
v02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
Remote Access Disabled
Enabled
When Enabled then a remote PC can via one
of the serial ports behave like a TTY terminal,
so that keyboard and monitor (in a terminal
window) is emulated by the remote PC. As
remote PC terminal program the Windows
Hyperterminal can be used.
Serial port number COM1
COM2
Setup which comport that should be used for
communication
Serial Port Mode
115200 8 n 1
57600 8 n 1
38400 8 n 1
19200 8 n 1
9600 8 n 1
Select the serial port speed
Flow Control
None
Hardware
Software
Select Flow Control for serial port
Redirection After BIOS POST Disabled
Boot Loader
Always How long shall the BIOS send the picture
over the serial port
Terminal Type
ANSI
VT100
VT-UTF8
Select the target terminal type
