Specifications
Inputs:
Outputs
Frequency Resp
Dyn. Range
Distortion:
.
Input Gain:
Output Gain
2/4 electronically balanced
Impedance: > 10k ohms.
CMRR : >65dB 50Hz - 10kHz.
: 4/6/8 electronically balanced
Source Imp: < 60ohms
Min. Load: 600ohm
Max. Level: +20dBm into 600 ohm
.: ½dB 20Hz-20kHz
-3dB @ 32kHz
:>116dB 20Hz-20k unwtd
< .02%@1kHz,+18dBm
Maximum Delay: 650 mS
Min Step Size: 0 3 S
+6dB to -40dB in 0.1dB steps
: +15dB to -40dB in 0.1dB steps and
mute
8 per Input / 9 Sections per Output
Filter Gain: +15dB to -30dB in 0.1dB steps.
Freq. Range: 19.7Hz - 32kHz, 1/36 octave steps.
Filter Q / BW: 0.4 to 128 / 2.5 to 0.008
(Sections switched to shelving response)
Low frequency: 19.2Hz - 1kHz
High frequency: 1kHz - 32kHz
Shelf gains: 15dB in 0.1dB steps.
Filters: 1 of each per output.
Freq. Range HPF: 10Hz - 16kHz
1/36 octave steps.
Freq. Range LPF: 35Hz - 22kHz
1/36 octave steps.
Responses:
1 Order 6dB/Oct.
Bessel/Butterworth/Linkwitz-Riley 12-24-48dB/Oct.
Bessel/Butterworth 18dB/Oct.
+
Parametric Equalisation
High and Lowpass Filters
st
Limiters
Connectors
Program Limiter:
Threshold: +22dBu to -10dBu
Attack time: 0.3 to 90 milliseconds
Release time: 2/4/8/16/32 x Attack time
“D-Max” Limiter:
Attack Time: -60uS
Release Time: Slow/Medium/Fast
2 x 24 Character LCD
Inputs: 3 pin female XLR
Outputs: 3 pin male XLR.
External: 9 pin DEE connector (RS232)
Power: 3 pin IEC
60 to 250V 15% @ 50/60Hz.
< 30 watts.
3.3kg. Net (4.7kg. Shipping)
: 1.75"(1U) x 19" x 11.8"
(44 x 482 x 300mm) excluding connectors
Transformer options available
Due to continuing product improvement the above
specifications are subject to change.
1.5mS (analogue in – analogue out @ 96kHz)
Display:
Power:
Consumption:
Weight:
Size
Latency:
Input meter:
Output meter: 2 x 6 point, -24dB to digital clip.
8 x 6 point, -24dB to +4dB into limit.
