Free Assign Routing
If none of the preset configurations are appropriate to the required system setup, it is possible to manually
select the routing of the crossover. This is achieved through the
.
Pressing will start the crossover design wizard, with the first option being to choose the routing.
The display will show
or whatever the current configuration is set to. Press until the display shows
And then press . The key will illuminate
for output 1, as will any relevant input keys,
showing which inputs are feeding output 1. The display
will also detail the current combination of inputs feeding
this output. To change the routing for any output, press
its
key, and then choose the required input
channel combination by just pressing the input
keys as appropriate. The input combinations can also
be stepped through in turn by pressing
, or
.
To complete the procedure, press . The wizard
will continue, and if the routing has been changed, all
outputs will be muted on exit.
Crossover Menu -> Design A Crossover
ENTER
Design A Crossover ->
Routing = 2 X 4 WAY *
BACK
Design A Crossover ->
Routing = Free Assign
ENTER EDIT
EDIT
EDIT
EDIT
NEXT
BACK
ENTER
Press EDIT input keys to
select/deselect inputs Press EDIT to show input
routing selection....
1 2
12
