Operating the SP27
Note about operation with AudioCore software.
The following operating information covers setup and control of the SP27 via the front panel controls only.
Please consult the manual supplied with this software for information regarding full computer control.
Switching on the unit will display a brief message detailing the unit type and software version running
== AudioCore DP4XX ==
==Software V 1.00 ==
and all LEDs will briefly illuminate. The unit will then begin its countdown to the wake-up procedure , during
which time the audio will fade up to the level last set. Metering will begin to operate when the fade-up starts.
- Design your crossover! To do this, press
, and use the
or
key to select '
and then press
. Use the
or
key to select
and then press
. Finally, use the
or
key to select the desired routing and follow the set-up wizard to
finalise your design.
-Note that when in a menu,
is always used to confirm selections. The current selection is marked with
an asterisk '*'.
-Use the
keys on each output channel with the
and
keys to select the high pass filters, low
pass filters, parametrics etc. Note that when designing a new crossover, the high and low pass filters will be
set to default values.
-Use the
keys on each input channel with the
and
keys to select the gain, delay and
parametrics available on each input.
Start-up procedure
Preliminary Set-up
The procedure below should be followed when first installing a SP27 unit.
MENU
BACK
NEXT
Crossover sub-
menu'
ENTER
BACK
NEXT
'Design a crossover'
ENTER
BACK
NEXT
ENTER
EDIT
BACK
NEXT
EDIT
BACK
NEXT
The wake-up time countdown may be adjusted in the SYSTEM menu - see page 23 for details.
For details about adjusting the routing if one of the standard configurations does not suit, see page 15.
Note that if no action is taken in menu mode, the unit will return to normal 'default' mode after
about twenty (20) seconds. Repeat the above directions to return to menu mode.
