Input Ganging and Output Ganging

Press EDIT keys to gang
flashing channel with selection

The method of linking inputs or outputs together during editing is achieved in the same way, so only crossover
(output) ganging will be explained here. Having selected Crossover Ganging from the menu under the
Crossover Sub-Menu, the current ganging set-up will be displayed. This will either be a preset selection as
would be useful in a standard crossover configuration – for example

…would be a logical ganging arrangement if the crossover was set up as a

– linking the control and

adjustment of all “Low” outputs together, and that of all “High” outputs together.

However, if the crossover has not been set up with a preset routing configuration, then it may be required to
set up the ganging to compliment this configuration. This is achieved using the Free Assign mode. This is
selected from the preset ganging choices, which are:

[all outputs independent]

Ganging=Free Assign

[choose ganging]

Selecting Free Assign and then pressing ENTER will begin the process of ganging outputs together using the
following simple rules:
- All outputs are ganged to the lowest number – so to gang

must be selected and then ganged to

- Outputs cannot share more than one ganging set – so for example output
unless they are ganged together as well. (

)

<-Crossover Ganging

Ganging=None

Ganging=1+3+5+7

2+4+6+8

4 x 2 way

Ganging=1+2+3+4+5+6+7+8[1 x 8 way]
Ganging=1+5 2+6 3+7 4+8

[4 x 2 way]

Ganging=1+3+5+7 2+4+6+8 [2 x 4 way]

3 & 5, 5

3 cannot be ganged to 2 and 4

Effectively 3 and 4 are ganged to 2 in this case

With these rules in mind, selecting and setting up gangs is quite straightforward.

Press a MUTE key to choose the output to gang – its LED will begin to flash, and an EDIT key will illuminate to
show which output it is currently ganged with. To change this selection, just press another EDIT key,
remembering that gangs work from the highest to lowest number. So, to gang outputs

– the display will show

<-Crossover Ganging

Ganging is cleared by selecting Ganging=None from the initial choices given above. The Input Ganging
procedure is identical to the crossover ganging, selectable under the Input Sub-Menu.

1 and 5, press MUTE 5

then EDIT 1

Gang Output 5 with 1

(- CrossoverGanging -)

Gang Output 1 w i t h 1

Press MUTE to select
channel to gang

MUTE begins to flash

EDIT LED will light to show lowest number in gang
