Operation MODEL 2080 / 2081 TURNTABLE SERIES
22 © ETS-LINDGREN L.P. – JANUARY 2003
REV C – PN 399228
RECOMMENDED PARAMETERS FOR THE
MODEL 2090 POSITIONING
CONTROLLER
DEVICE 2
Parameter Value Description
P1
0 Turntable
P2
0 Standard Turntable
P3
000 Infinite Scan Count
P5
1 Non-continuous rotation
P8
2.5 2.5 Second reverse delay
P9
9 Primary GPIB address 9
b1
000 User options disabled
c
3600 3600 encoder counts per meter
S0
-1 Step speed = run speed
S1
31 Speed 1 ~12.5% of max speed
S2
63 Speed 2 ~25% of max speed
S3
95 Speed 3 ~37.5% of max speed
S4
127 Speed 4 ~50% of max speed
S5
159 Speed 5 ~62.5% of max speed
S6
191 Speed 6 ~75% of max speed
S7
223 Speed 7 ~87.5% of max speed
S8
255 Speed 8 = max speed
Oc
On Overshoot compensation enabled
EDITING MODEL 2090 POSITIONING
CONTROLLER CONFIGURATION
PARAMETERS
To edit a configuration parameter, press the PARAM key to
display the current parameter. Pressing the PARAM key
repeatedly will scroll down through the parameter list, showing
each parameter in turn. While viewing a parameter, the STEP
keys (INC/DEC) may be used to scroll up or down the parameter
list. This reduces the effort necessary to scan through a long
parameter list using the PARAM key. Pressing any of the
LIMIT/POSITION selection keys will return the display to that
