MODEL 2080 / 2081 TURNTABLE SERIES Electrical Installation
© ETS-LINDGREN L.P. – JANUARY 2003 19
REV C – PN 399228
ELECTRICAL INSTALLATION
CAUTION It is important that this electrical installation
procedure be performed by a qualified electrician, in accordance
with local and national electrical standards prior to energizing the
unit.
CAUTION Ensure power is off and secured before proceeding
further. The voltage select switch on the Motor Base Unit must be
set to the proper mains voltage before power is applied to the unit.
The Motor Base Unit of the Model 2080/2081 Turntable allows for
the selection of either 115 or 230 VAC mains input voltage. This
selection should be made during installation and prior to
connecting the Motor Base Unit to the power mains.
On the front of the enclosure for the Motor Base Unit, locate the
voltage select switch which is marked for 115 and 230. Switch to
the appropriate position which corresponds to the mains voltage to
be applied. This switch provides a means of selecting the voltage
to be applied to the drive motor, electric brake and internal power
supply.
Determine the mains voltage to be applied to the Motor Base Unit.
The branch circuit supplying power to the motor base should be
protected from excess current according to local electrical codes.
Check that the conductor size is adequate for the motor load with
respect to the distance from the mains source. Improperly sized
conductors will lead to a high voltage drop in the power
conductors and cause reduced starting torque. This condition could
lead to premature motor failure.
CAUTION Keep all body parts away from the drive gears and
drive belt when the turntable is energized. Do not operate the
turntable with the protective guards removed.
