Introduction | 11
Optional Part Description Part Number
Free-Space Mount Kit
• Light duty free-space mount kit is included with all light duty
mast assemblies
• Not compatible with medium duty MAPS 2115 mast assembly
107549
Free-Space Mount Kit
• Medium duty free-space mount kit is not included with
medium duty mast assembly
• Not compatible with light duty MAPS 2110 mast assembly
107559
Laptop Mount for medium duty MAPS 2115
• To mount laptop or similar device
• EUT rotation axis is at center of EUT
108279
Mounting Adapters for Model 3160 Standard Gain Horn Antennas
• To mount to medium duty MAPS 2115
• Requires antenna mount; also requires an extension to be attached to the rotating
axle of the upper mast assembly
• If mounting two antennas that require the same extension, only one extension is
required
Antenna Mount Extension
– 3160-05 Standard Gain Horn Antenna 110758 110759
– 3160-06 Standard Gain Horn Antenna 108416 108793
– 3160-07 Standard Gain Horn Antenna 108417 108793
– 3160-08 Standard Gain Horn Antenna 108418 108793
Dipole Mount Base 107505
CTIA Ripple Antenna Mount Kit
• To mount loops and dipoles during the CTIA ripple test
• Specify height as –NNNN
For example, 72 inches is –7200 and 59.5 inches is –5950
107553-NNNN
