40 | Doors
Door Operation for Type G
This door is most often installed on large chambers for large equipment access.
Operating and maintenance instructions differ quite significantly from the
standard swing doors; therefore, individual operation and maintenance manuals
are issued with each door fitted to a chamber.
Adjusting RCM 1 Hinges
Adjustment is the same for left and right hinges. All hinges must be aligned
together.
U P - AND -D OWN A DJUSTMENT
1. Open the door.
2. Place a hex key in the top of the hinge pin.
3. Turn the hinge pin clockwise to move the door leaf up; turn the hinge
pin counterclockwise to move the door down. Approximately three to
four turns are typically required to set the correct spacing between
door and the jamb; for example, 1/8 in (3 mm) to 5/32 in (4 mm).
4. Close the door.
5. Repeat as required.
S IDE - TO -S IDE A DJUSTMENT
1. Adjust each hinge as required to move either the top or bottom of the
door leaf.
2. Close the door. Do not loosen the dome head nuts on the frame side of
the hinge.
3. Loosen the M5 x 10 mm grub screw on the side of the hinge fitted to
the door leaf.
4. Loosen the three dome nuts on the hinge (3/8-in diameter).
5. Move the door leaf to set the correct spacing between door and the
jamb. Tighten dome nuts and torque to 12 ft lb.
