Shielding | 29
4.0 Shielding
The RF shield must be installed by or the
installation supervised by a qualified individual.
Series 81 Modular Shielding
T YPE : Modular Systems—Series 81 (28 ga. steel)
D ESCRIPTION : Two layers of sheet steel laminated to a wood core.
Modular panels joined with 11 ga. ETS-Lindgren
framing system using 1/4 in screws on 4-in centers.
O PERATION :
After the enclosure is installed, the interior finishes should not be
changed. It is important that:
1. Liquids are not spilled on the shielding.
2. Only ETS-Lindgren RF penetration be used through the walls,
floors, and ceiling.
3. Framing screws are not used to secure any item to the wall.
4. All screws are tightened to 90-in lb torque. If screws are
removed, they must be reinstalled with the use of a calibrated
torque wrench or screw gun.
