Maintenance
| 13
3.
Inspect finger stock; install new finger stock where necessary.
4.
Wipe knob edge on door leaf with a clean cloth wetted with cleaning
agent.
A
NNUAL
M
AINTENANCE
1.
Perform maintenance as described in
Monthly Maintenance (see
previous section).
2.
During inspection of finger stock, count the number of patches that
have been replaced. If more than five patches have been replaced,
remove all finger stock (part# 81D-6L) and vinyl seal shield
(part# VS-100) from the channel. Install new finger stock and new seal.
3.
Lubricate tuner bearing grease nipples using standard bearing grease.
4.
Check motor supply and signal cable condition external to the
chamber.
5.
Remove excess dust from motor (and amplifier, if fitted).
R
EPLACING
F
INGER
S
TOCK AND
V
INYL
S
EAL
1.
Remove old finger stock and vinyl seal using needle-nose pliers.
2.
Clean channel.
Use the cleaning agent as described in the manufacturer instructions.
3.
Cut exact lengths of finger stock for each of the four sides of the frame.
4.
Cut exact length of vinyl seal.
5.
Starting in upper left corner, install first row of finger stock down the
entire side of the frame.
6.
Lubricate fingers and channel again.
7.
Again starting in the upper left corner, insert second row of finger stock
down the entire side of the frame. Fingers should be gently pressed
into position one at a time until they are locked in place.
8.
Repeat steps 5, 6, and 7 for each of the remaining three sides of the
frame.
